Description
The Wunderlich ULTIMATE plus supplementary bars complement the ULTIMATE tank protection bar, providing a seamlessly integrated extra layer of protection for the flanks of the BMW R 1300 GS Adventure.
Features
- These ULTIMATE plus supplementary bars complement the ULTIMATE tank protection bar #13215-002 and provide additional protection for the Adventure's flanks
- They act as a coupling element between the rack base and the lower tube support, ensuring added stiffness in the tube network
- The forces and moments are distributed across two additional mounting points on both the right and left sides
- The shape of the supplementary bars further aids in the elastic absorption of peak stress loads
- This additional protection increases passive safety and reduces the risk to the rider's legs in the event of a fall
- Perfect fit
- Integrated solution from a single mould
- Simple and quick assembly
Note
The side bracket included with the supplementary bar replaces the side bracket of the tank protection bar. It connects the tank protection bar with the supplementary bar, serving as a shared side bracket for both.
Technical Specifications
- Material
- Protection Bars
- Precision steel tubing with high tensile strength and elongation at break, carefully handcrafted, radii precisely formed using CNC tube bending machines, and then cleanly welded. Carefully finished and powder-coated in black.
- Material
- Side Bracket
Made from aluminium, carefully finished
- Dimensions
- Tube diameter: 25 millimetres
- Colour
- Protection bar structure and side bracket powder-coated in black - monochromatic
