INA - Replacement Ball Bearing for KTM/Husqvarna Balancer Shaft - Type HK2512-B

Features

• The bearings are particularly suitable for applications with a very small radial section height on account of their very low cross-sectional height
• Used if the housing bore is not suitable as a raceway for needle roller and cage assemblies
• Can support high radial loads
• Require a considerably smaller radial design envelope than machined needle roller bearings
• Usually run directly on the shaft
• Permit relatively high speeds
• Easy to mount
• Require no additional means of axial retention
• Can be readily used to close off the shaft ends of bearing positions
• Result in particularly compact, cost-effective and economical bearing arrangements
• AS1 with lubrication hole from HK0609
• 11000 N dynamic/15200 N static

Technical Specifications

• Cage Material : Sheet Steel
• Closure Type : Open
• Maximum Speed : 10200 rpm
• Series : HK Series
• Temperature Rating : -30 to 140 deg C
• Bore Diameter : 25 mm
• Outside Diameter : 32 mm
• Number of Rows : 1
• Width : 12 mm
• Load Capacity : 15200 N

Replaces KTM/Husqvarna Parts

• 0617253212
